Belliss & Morcom Governor Overhaul

This unit is a rare Governor by Belliss and Morcom. The company which were founded in 1852 in Birmingham, are now a division of Ingersoll Rand based in Redditch.  The actual Governor is thought to be around at least 45 years old and obviously this particular model and parts now obsolete. We were unable to determine when it had previously been overhauled.

We fully stripped, chemically cleaned and inspected every inch of this governor. After inspection it was found that the output power piston trip mechanism housing had a large crack through the casting, and major wear throughout.

Specialist cast iron welding was carried out on the damaged part of the case and EGS manufactured all obsolete parts.

The unit was then carefully rebuilt, paint sprayed and tested to specification.

This unique Governor took 8 weeks to complete and our customer and team were all very impressed with our final achievement when fitted back into the petrochemical plant.

Below photos of before and after overhaul.

Steam Valve Overhaul for Sulzer

The Steam turbine combined trip and throttle valve was received in a very poor condition and appeared to have not been used for some considerable time.
Trip and throttle valves are integral to the safety and precisely control the speed / load of the steam turbine, typically drive an alternator, pump or fan.
Steam valves generally get very rusty, due to the nature of the harsh environment, as you can see from the before photograph.

Sequence of overhaul;
The first step we take when performing an overhaul on any valve is to photograph its initial state and also as we gradually strip the valve, more photos are taken.
The valve is then dismantled and cleaned by paint stripping and bead blasting to remove all rust and dirt, then chemically cleaned.
Once all parts are clean, they are then laid out and inspected for wear, damage and corrosion. Only then our technicians will ascertain what will need replacing.
A Standard overhaul kit was fitted, in addition to valve stems, pins, main studs, washers, adjusting screws, main gaskets used plus machining on some major parts carried out.
The valve was then meticulously re-built and mechanically tested to ensure the unit was back to original specification.

The finished valve was dispatched in a bespoke wooden packing case and delivered safely back to the customer by our own EGS transport.

For all enquiries, please contact wayneward@egsgov.com



Steam Turbine Actuator Overhauls

We have just completed another successful overhaul job of 4 large steam valve actuators and Voith Way Valves for steam turbines situated in a recycling plant. This particular plant recycles domestic waste into electrical energy, which subsequently exports to the National Grid.
This job was interesting for our engineers, as all 4 actuators were received in a stripped and broken down state, as the plant engineers had tried to examine the actuators themselves and in turn had severely damaged vital components on the 4 units.
After all components were chemically cleaned and stripped of any paint, they were then fully inspected to see the extent of the destruction. Major components were replaced as well as ‘O’ rings, piston rings, seals, receptacles and all consumable fasteners renewed.
Our machine shop carried out bore honing to suit over sized pistons. Grinding and re-chroming piston stems to standard size. We also manufactured piston bearing/ seal housings.
Each steam valve actuator uses a Voith Way Valve, so these were also overhauled. The ‘Way Valve’ controls the hydraulic pressure, monitoring the feedback (LVDT) positioning sensor for each valve when fitted to the steam turbine.
Once all units were carefully re-assembled and painted a vibrant blue colour, they then had to be tested. Our Applications Engineer has built customised test equipment to aid in the examination of the output figures that each complete actuator should read. The Voith over speed trips were tested to factory settings. Each unit took approximately 2 hours to gain full accurate readings.
On completion of test, all equipment was delivered to site by our EGS Engineers, who were on hand to assist with installation.
With a lot of careful planning and production meetings, EGS were able to complete and turnaround this job in 4 weeks.

Help Marie raise money for Charity

Marie has signed up for a Trek across the Sahara Dessert!

She has set herself this challenge of a lifetime to help support a local charity called St Helena Hospice, they help people to live well and die with dignity and choice. Something which is close to Marie.

She will spend 5 days in Morocco in February 2018, trekking 40k across the dessert.

Marie has a fundraising target of £1700, which she needs to reach by December 2017.

You can donate to her Just Giving pagebadge10 here. Please support her all you can.



Good Luck Marie, and Well Done for raising money for such a great cause.



Congratulations to our Store man

Congratulations to our Store man, Ian who celebrates 25 years here at EGS

Another long standing employee of Essex Governors has become a member of the elite 25 years club!

Ian was congratulated by our Director Wayne Ward and the rest of the company where he was presented with a gift for his long service.

Ian joined  a small EGS team of approximately 6 employee back in 1990, when he originally started working as a parts cleaner, then moved to engine rebuild and stores.

The company has since grown considerably around Ian, including the stores, which is now 5 times the size!. Ian’s main job is to co-ordinate the stores and ensure all orders are picked, packed and despatched to his high standard.

Ian said “ Time has flown at EGS, I can’t believe I been here 25 years already!”

EGS to the Rescue

We have just saved the day and delivered three super red hot urgent governors that have be fitted back on board a cruise liner that encountered engine problems while sailing around the Mediterranean with passengers on board.

The three generator governors were overhauled here at EGS and delivered to Port where the motor vessel was docked within just three days.

The ship has now safely departed, carrying on its journey with around 800 passengers.

30 Years in Business

This year we are proud to be celebrating our 30th Anniversary. Since the company was founded in 1984 by Andrew Whyte it has grown from a single workshop with 3 staff to a well-established successful business. From starting off in a small workshop, the business has moved premises on four occasions and each time grown in size. Along the way EGS has been appointed as a channel partner for General Electric (G.E).

We supply to some of the top leading companies within the UK, across a wide range of sectors, including marine, rail, utility, industrial and petrochemical industries. Some of our dedicated engineers have travelled far and wide to reach customers abroad and help to resolve their governor related issues. From attending a luxury cruise ship in tropical climates to local incineration plant we have got the job done!

Year after year our amazing staff have provided outstanding workmanship and we are fortunate enough to hold many long serving employees and customers worldwide, our company would not have developed without them … and so we continue on our path of growth and excellence….30pics

How NOT to overhaul a governor

We received a UG8 Governor clearly showing signs that it had undergone a bad and cheaply done overhaul – this was a prime example of how a governor should not be overhauled!

  1. Once this particular governor was stripped down it was clear that the parts had been shot blasted, which included parts made to fine tolerance e.g. pilot valve and bushing. Some internal parts are coated and by using harsh blasting methods the coatings / layers will be removed and service life will be considerably reduced.                                                                                                                We carry out vapour blasting on castings and non fine tolerance items, this is a gentler and finer process that does not cause damage to parts. The parts are then thoroughly cleaned and inspected for wear / damage.

2. It was evident that this governor had not been updated with the latest specification of parts but instead the old parts had merely been cleaned and re-assembled.                                                                                                           Once our inspection has taken place ALL worn / corroded / damaged parts are replaced with NEW and updated spares.

  1. It was obvious that some castings showed clear signs of rust and pitting. There was no protective coatings on any of these parts, it was easy to tell that some of the castings had not been renewed as they should have been.                                                                                           We ensure that our supplied castings have a protective layer on the metal as this protects parts from harsh conditions causing slower wear, meaning a longer life in service.

As this governor was in such a bad state it was deemed uneconomical to repair, so our customer opted for a reconditioned unit.

The EGS Brand Governor

Quality built Governors at competitive pricespgpls

Welcome back to EGS …. This photo is one of our latest orders for 8 new PGPL Governors and 4 UG8 Governors. These are EGS BRAND GOVERNORS … What’s the difference to WOODWARD brand Governors you ask?? Well EGS governors are the same in build and specification to Woodward, apart from they are built and assembled here in our workshop in the UK by our trained and experienced technicians. All parts are quality Woodward parts and Governors are tested on Woodward test stands by our Woodward trained test engineer. All Governors are supplied with 12 months warranty cover and can be shipped worldwide.

EGS offer ..

  • All new build and overhauled governors are very competitively priced
  • A wide range of spare parts are available from stock
  • Exchange and Reconditioned Governors available
  • Onsite Engineers  / Emergency assistance
  • Retrofit projects
  • Governor Training courses tailored to specific requirements



How can we help you?

Many of our customers don’t realise that we can carry out a variety of works, all to do with mechanical or electrical governing equipment.  We are your one stop governor shop!

We serve worldwide, no destination is too far! Our engineers and training supervisors are happy to travel and assist you with any governing difficulties. We can transport governors and spare parts to your preferred destination. EGS can also help you with technical assistance by phone.

Our services include; Supply of new or reconditioned governing equipment, governors on exchange basis, retrofit projects, test & repairs, overhauls including gold seal prices, spare parts, onsite engineers and training courses tailored to suit your individual needs.

Makes include;  Woodward – Regulateurs Europa – Diesel Kiki / Zexel

We have supplied some top companies including; Rolls Royce, E:ON, British Sugar …. The list could go on!

For any enquiry email info@egsgov.com or speak to our friendly office team on 01206 242000
